    Customize Hydraulic Power Pack

    Eva Hydraulic Solutions > Our Products > Hydraulic Power Packs > Customize Hydraulic Power Pack
    // About Hydraulic Power Packs

    Customize Hydraulic Power Pack

    A Customized Hydraulic Power Pack (HPP) is designed exactly to match your machine, application, and site conditions. Unlike standard units, customized power packs provide the right combination of components to optimize performance for a specific task.

    // About Hydraulic Power Packs

    Key Parameters for Customization

    Power Supply

    • Single Phase: 230V AC (common for small machines)
    • Three Phase: 415V AC (industrial use)
    • Motor brand & efficiency (IE2 / IE3)
    • Motor protection: Thermal overload, MCB

    Oil Tank (Reservoir)

    • Capacity: 20L to 500L+
    • Material: MS / SS
    • With baffle plate, drain plug, breather
    • Oil level & temperature indicator

    Pump Selection

    • Gear Pump – economical, low to medium pressure
    • Vane Pump – quieter operation
    • Piston Pump – high pressure & precision
    • Flow rate (LPM)
    • Working pressure (bar)

    Valve Manifold & Controls

    • Direction Control Valve (manual / solenoid)
    • Pressure Relief Valve
    • Flow Control Valve
    • Check Valve / Sequence Valve
    • CETOP mounting / custom manifold block

    Filtration System

    • Suction strainer
    • Return line filter
    • Pressure line filter (optional)
    • Filter clogging indicator

    Cooling / Heating (Optional)

    • Air oil cooler / Water oil cooler
    • Oil heater (for cold environments)
    • Temperature switch

    Electrical Panel

    • Start/Stop push buttons
    • Contactor & overload relay
    • Pressure switch
    • PLC / HMI (if automation required)
    • Control voltage: 24V DC / 110V / 230V

    Mounting & Construction

    • Compact skid-mounted / vertical / horizontal
    • Noise reduction enclosure
    • Anti-vibration pads
    • Weatherproof (IP55 / outdoor)

    Application-Based Customization Used for:

    • Hydraulic press
    • Scissor lift
    • Power press
    • Injection molding machine
    • Special purpose machines (SPM)
    • Material handling equipment
    // About Hydraulic Power Packs

    Components You Can Customize

    • Power source:Electric motor for indoor or stationary use, or diesel engine for mobile or remote equipment
    • Pump configuration:Gear, vane, or piston pumps with fixed or variable displacement
    • Reservoir (tank) size:Based on system volume and heat dissipation requirements
    • Valves and controls:For precise flow, direction, and pressure control
    • Filtration system:Multi-stage filtration, breathers, and fluid analysis ports
    • Cooling system:Air- or water-cooled heat exchangers
    • Enclosure and mounting:Designed to suit space and environmental conditions

    Applications of Customized Hydraulic Power Packs

    • Construction machinery:Excavators, cranes, loaders
    • Industrial manufacturing:Machine tools, presses, automation systems
    • Marine industry:Winches, steering systems, cranes
    • Aerospace:Test rigs, flight control systems, landing gear operations
    • Material handling:Conveyors, hoists, lifts
    • Energy and utilities:Wind turbines, hydroelectric plants, oil & gas servicing
    • Automotive:Assembly, braking, steering, suspension systems
    • Mobile equipment:Scissor lifts, trailers, tipping trucks

    Information Needed to Design Your Power Pack

    To provide the exact configuration, the following details are required:

    • Required pressure (bar)
    • Required flow (LPM)
    • Single phase or three phase supply
    • Type of actuator (cylinder / motor) and quantity
    • Duty cycle (continuous / intermittent)
    • Application and working environment
